Main Performance Specifications
- Product specification: DN 40–600
- Nominal pressure: PN1.6MPa
- Applicable media: water, air, oil, acid
- Applicable temperature: -20 ~ 120°C
- Thread standard: BSPT/BSP/NPT/DIN/JIS/RC/G
- Design and manufacture: GB/T 12237/ANSI B16.34
- Connection size: GB/T 9113.1/ASME B16.5 CLASS150
- Inspection and test: GB/T 13927/API 598
Material of Main Parts
- Body: CF8M, CF8
- Bonnet: CF8M, CF8
- Valve disc: CF8M, CF8
- Seat: Fluororubber
- Line: Teflon
- Spring: SS316, 304
