Application Range
Usually used for transportation of non-lubricant, causticity, sticking liquid, or the liquid without solid grain or thread, or for sanitary transportation. It can be used for the liquid under the temperature of 20-80°C, the viscosity for 5-5000cst.
Use
Suitable for machinery, petroleum, chemistry, food stuff, medicine, metallurgy, brewage.
Structure Characteristic
The synchronous gear powered drive system and the liquid transmission rotor are fixed in different pump cavity, so different and more suitable design can be applied to make up a credible system.
On the base of FXA, we designed a stage bearing on the out-cover. Which raises the pressure and the user also can choose pumps with the mechanical seal or packing seal.
