Main Performance Specifications
Product specification: DN15~50/NPS 1/2”~2”
Nominal pressure: PN 63/1000WOG
Applicable temperature: -20 ~ 150°C
Design and manufacture: GB T12237/ANSI B16.34
Thread standard: according to BSPT/BSP/NPT/DIN/JIS/RC/G
Dimension reference: GB T 9113.1/ASME B16.5 CLASS 150
Length: GB/T 12221/ASME B16.1
Inspection and test: GB/T 13927/API 598
