Main Performance Specifications
- Product specification: NPS 1/4"~3" (DN 6~80)
- Nominal pressure: PN 1.0/1.6MPa
- Applicable media: water, oil, acid
- Applicable temperature: -50~232°C
- Thread standard: according to BSPT/BSP/NPT/DIN/JIS/RC/G
- Connection size: GB/T 9113.1/ASME B16.5 CLASS150
- Structural length: GB/T 12221/ASME B16.1
- Design and manufacture: GB/T 12237/ANSI B16.34
- Inspection and test: GB/T 13927/API 598
