Main Performance Specifications
Product specification: NPS 1/2''–4''
Nominal pressure: PN 1.0/1.6MPa
Applicable media: water, air, oil
Applicable temperature: -20 ~ 120 °C
Thread standard: according to BSPT/BSP/NPT/DIN/JIS/RC/G
Structural length: GB/T 12221/ASME B16.1
Design and manufacture: GB/T 12224/ANSI B16.34
Inspection and test: GB/T 13927/API 598
