Design Standard: API 6D, ISO17292, ASME B16.34, API608 ISO14313
NACE: MR0175, ISO15156
End To End: API 6D, ASME B16.10, EN558, EN12982
Connection: ASME B16.5, ASME B16.47A, ASME B16.25, EN1092, EN12627
Design Feature: Anti blow out stem, Anti-static device, Fire safe design, Double block & bleed, 2 & 3pcs body, Soft or metal seat, Side entry
Material: Carbon Steel, Low-temp. Carbon steel, Austenitic stainless steel, Al-Br & Other steel series material as client required.
Operation: Lever, Gearbox, Pneumatic, Electric, Oil over gas
Test and Inspection Standard: API 6D, API 598, EN12266
Normal Size: 2” – 48”, DN50-DN1200
Pressure Rating: Class150LB-2500LB, PN10-PN420
